Product gallery · 1 view
Sensors & meters / CN-2fb50b3be9ec
Conductivity/TDS/Resistivity/Salinity Meter DDG-2080X
Development import — not technically reviewed. Manufacturer-sourced catalog entry. Final specifications, availability, and suitability require confirmation.
ManufacturerBOQU
Reference priceRequest quote
Minimum orderTo confirm
Trade termsTo confirm
Pipe sizesTo confirm
MaterialTo confirm
ConnectionTo confirm
Instrument specifications
FunctionsEC / Resistivity / Salinity / TDS
Measuring range0.00uS-2000mS / 0.00-20.00MΩ-CM / 0.00-78.00 g/Kg / 0-133000 ppm
Resolution0.01/0.1/1 / 0.01 / 0.01 / 1
Accuracy±1%F.S. / ±1%F.S. / ±1%F.S. / ±1%F.S.
Temp. compensationPt 1000/NTC30K
Temp. range-10.0 to +130.0℃
Temp. compensation range-10.0 to +130.0℃
Temp. resolution0.1℃
Temp. accuracy±0.2℃
Cell constant0.001 to 20.000
Ambient temperature range0 to +70℃
Storage temp.-20 to +70℃
DisplayBack light, dot matrix
EC current output1Isolated, 4 to 20mA output , max. load 500Ω
Temp. current output 2Isolated, 4 to 20mA output , max. load 500Ω
Current output accuracy±0.05 mA
RS485Mod bus RTU protocol
Baud rate9600/19200/38400
Maximum relay contacts capacity5A/250VAC,5A/30VDC
Cleaning settingON: 1 to 1000 seconds, OFF: 0.1 to 1000.0 hours
One multi?function relayclean/period alarm/error alarm
Relay delay0-120 seconds
Data logging capacity500,000
Language selectionEnglish/traditional Chinese/simplified Chinese
Waterproof gradeIP65
Power supplyFrom 90 to 260 VAC, power consumption < 5 watts
Installationpanel/wall/pipe installation
Manufacturer-reported specifications
Functions: EC / Resistivity / Salinity / TDS Measuring range: 0.00uS-2000mS / 0.00-20.00MΩ-CM / 0.00-78.00 g/Kg / 0-133000 ppm Resolution: 0.01/0.1/1 / 0.01 / 0.01 / 1 Accuracy: ±1%F.S. / ±1%F.S. / ±1%F.S. / ±1%F.S. Temp. compensation: Pt 1000/NTC30K Temp. range: -10.0 to +130.0℃ Temp. compensation range: -10.0 to +130.0℃ Temp. resolution: 0.1℃ Temp. accuracy: ±0.2℃ Cell constant: 0.001 to 20.000 Ambient temperature range: 0 to +70℃ Storage temp.: -20 to +70℃ Display: Back light, dot matrix EC current output1:
